Removable cast aluminium hood

SINGLE phase supply, 3 phase motor

Motor & two stage gearbox direct drive

Inverter driven

Adjustable speed, acceleration and deceleration

No springs required or counterweights

Pre-wired loop detector bases for single channel safety and entry/exit control

Heavy duty roller plunger limit switches

Programmable Logic Control – c/w fault diagnostic on screen display

Manual override in case of power failure

Comes complete with M12 anchor shield bolts

1.5 Amp power supply for additional access control

Ideal for Underground car Parks with articulated arm

Used on smaller car park we suggest a maximum boom length of 5M

Specification
CE Approved (Conforms to BS6571)
Maximum Boom length
6.0 Metres
Boom Diameter
86mm x 60mm Oval
Opening/closing time
2.0 – 6.0 Seconds (adjustable)
Drive Unit
3 Phase Motor & Wormed Gearbox
Power Supply
SINGLE Phase 230v, 50Hz, 5 Amps
Cycles
100% Continuous Duty Rating
Dimensions
382mm x 359mm x 980mm

Accessories
Pre-Wired Loop Detector Bases
Control Panel
TELEMECANIQUE PLC & INVERTER
Auxiliary Power
1.5 Amp 24v Supply
Fixings
M12 Anchor Shield Bolts Included
Spring-Counterweights
NOT REQUIRED
Finish
Aluminium cabinet & lid, Powder Coated
Settings
Programme Configuration as Standard
Adjustable Acceleration and Deceleration
